Intel Core i3-7020U

Intel i3-7020U

El Intel Core i3-7020U es un procesador de doble núcleo de la arquitectura Kaby Lake. Ofrece dos núcleos de CPU con una frecuencia de 2,3 GHz (sin Turbo Boost) e integra HyperThreading para trabajar con hasta 4 hilos a la vez. Las diferencias arquitectónicas son bastante pequeñas comparadas con la generación Skylake, por lo que el rendimiento por MHz debería ser muy similar. El SoC incluye una controladora de memoria DDR4 de doble canal y una tarjeta gráfica Intel HD Graphics 620 (programada a 300 - 1000 MHz). Está fabricado en un proceso FinFET mejorado de 14nm en Intel. En comparación con el antiguo i3-7100U, el nuevo i3-7020U tiene una velocidad de reloj 100 MHz inferior (núcleos de la CPU) y, por tanto, es el modelo de entrada actual de la línea Core i3. El similar Pentium Gold 4415U ofrece menos caché (2 frente a 3 MB) y una GPU más lenta.

Arquitectura

Intel utiliza básicamente la misma micro arquitectura en comparación con Skylake, por lo que el rendimiento por MHz no difiere. El fabricante sólo ha retocado la tecnología Speed Shift para realizar ajustes dinámicos más rápidos de voltajes y relojes, y el proceso mejorado de 14nm permite frecuencias mucho más altas combinadas con una mayor eficiencia que antes.

SerieIntel Kaby Lake
Nombre códigoKaby Lake

Serie: Kaby Lake Kaby Lake

Intel Core i7-7700K4.2 - 4.5 GHz4 / 8 cores8 MB L3
Intel Core i7-77003.6 - 4.2 GHz4 / 8 cores8 MB L3
Intel Xeon E3-1535M v63.1 - 4.2 GHz4 / 8 cores8 MB L3
Intel Core i7-7920HQ3.1 - 4.1 GHz4 / 8 cores8 MB L3
Intel Core i7-7700T2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i5-7600K3.8 - 4.2 GHz4 / 4 cores8 MB L3
Intel Xeon E3-1505M v63 - 4 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HQ2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HK2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7700HQ2.8 - 3.8 GHz4 / 8 cores6 MB L3
Intel Core i5-75003.4 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i5-7440HQ2.8 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i7-7567U3.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7660U2.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7600U2.8 - 3.9 GHz2 / 4 cores4 MB L3
Intel Core i5-7300HQ2.5 - 3.5 GHz4 / 4 cores6 MB L3
Intel Core i5-7500T2.7 - 3.3 GHz4 / 4 cores6 MB L3
Intel Core i5-7287U3.3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-7560U2.4 - 3.8 GHz2 / 4 cores4 MB L3
Intel Core i5-7267U3.1 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7360U2.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-7500U2.7 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7300U2.6 - 3.5 GHz2 / 4 cores3 MB L3
Intel Core i5-7260U2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i5-7200U2.5 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i3-7100H3 GHz2 / 4 cores3 MB L3
Intel Core i3-7167U2.8 GHz2 / 4 cores3 MB L3
Intel Core i7-7Y751.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y571.2 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y541.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i3-7100U2.4 GHz2 / 4 cores3 MB L3
Intel Core m3-7Y321 - 3 GHz2 / 4 cores4 MB L3
Intel Pentium Gold 4415U2.3 GHz2 / 4 cores2 MB L3
Intel Core m3-7Y301 - 2.6 GHz2 / 4 cores4 MB L3
Intel Celeron 3965U2.2 GHz2 / 2 cores2 MB L3
Intel Core i3-7020U « 2.3 GHz2 / 4 cores3 MB L3
Intel Celeron 3867U1.8 GHz2 / 2 cores2 MB L3
Intel Celeron 3865U1.8 GHz2 / 2 cores2 MB L3
Intel Pentium Gold 4425Y1.7 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4415Y1.6 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4410Y1.5 GHz2 / 4 cores2 MB L3
Intel Celeron 3965Y1.5 GHz2 / 2 cores2 MB L3
Velocidad de reloj2300 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 33 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)15 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
ConectorBGA1356
RecursosDual-Channel DDR4 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel HD Graphics 620 (300 - 1000 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$281 U.S.
Fecha de anuncio08/30/2016
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
227 Points (1%)
+ 1 mas detalles   - Ocultar tabla de comparación
0153045607590105120135150165180195210225Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
93 Points (26%)
+ 1 mas detalles   - Ocultar tabla de comparación
AMD A4-1200
19 -80%
...
Intel Core i3-5015U
85 -9%
Intel Core i3-5010U
85.3 -8%
Intel Core i5-3337U
88.3 -5%
Intel Pentium Gold 4417U
89 -4%
Intel Core i5-L16G7
89.5 -4%
Intel Core M-5Y71
90.5 -3%
Intel Core M-5Y70
91 -2%
AMD 3020e
92 -1%
Intel Pentium Gold 5405U
92.6 0%
Intel Core i3-7020U
93
Intel Core M-5Y31
93.3 0%
Intel Pentium Gold 4415U
94 1%
Intel Core i3-4000M
94.2 1%
Intel Core i3-7100U
94.3 1%
Intel Core i3-6100U
96.1 3%
Intel Core i5-4200U
96.7 4%
AMD Ryzen Embedded R1505G
97.3 5%
Intel Core i3-5157U
98 5%
Intel Core i5-4300U
98.4 6%
...
AMD Ryzen 9 7945HX3D
311 234%
max:
Intel Core Ultra 9 285K
355.5 282%
0%
100%
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
3588 puntos (22%)
+ 1 mas detalles   + Mostrar tabla de comparación
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
8083 puntos (6%)
+ 1 mas detalles   + Mostrar tabla de comparación
WinRAR - WinRAR 4.0
1920 puntos (3%)
+ 1 mas detalles   + Mostrar tabla de comparación
X264 HD Benchmark 4.0 - x264 Pass 2
15.6 fps (5%)
+ 1 mas detalles   + Mostrar tabla de comparación
X264 HD Benchmark 4.0 - x264 Pass 1
80 fps (18%)
+ 1 mas detalles   + Mostrar tabla de comparación
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (4%)
+ 1 mas detalles   + Mostrar tabla de comparación
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (4%)
+ 1 mas detalles   + Mostrar tabla de comparación
TrueCrypt - TrueCrypt AES
1.4 GB/s (4%)
+ 1 mas detalles   + Mostrar tabla de comparación
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
12 s (3%)
+ 1 mas detalles   + Mostrar tabla de comparación
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
28 s (1%)
+ 1 mas detalles   + Mostrar tabla de comparación
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
706 s (3%)
+ 1 mas detalles   + Mostrar tabla de comparación
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
4821 puntos (9%)
+ 1 mas detalles   + Mostrar tabla de comparación
Geekbench 3 - Geekbench 3 32 Bit Single-Core
2221 puntos (43%)
+ 1 mas detalles   + Mostrar tabla de comparación
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
4977 puntos (8%)
+ 1 mas detalles   + Mostrar tabla de comparación
Geekbench 3 - Geekbench 3 64 Bit Single-Core
2335 puntos (35%)
+ 1 mas detalles   + Mostrar tabla de comparación
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
